| Anchor Bolt Size (D x L x C x T) | Drawing | ||||
| Diam. | Length | Hook | Thread | ||
| * 1/2 | 6 | 2 | 1 1/2 | ||
| * 1/2 | 8 | 2 | 1 1/2 | ||
| * 1/2 | 10 | 2 | 1 1/2 | ||
| * 1/2 | 12 | 2 | 1 1/2 | ||
| * 1/2 | 14 | 2 | 1 1/2 | ||
| * 1/2 | 16 | 2 | 1 1/2 | ||
| * 1/2 | 18 | 2 | 1 1/2 | ||
| 5/8 | 6 | 3 | 3 | ||
| 5/8 | 8 | 3 | 3 | ||
| 5/8 | 12 | 3 | 3 | ||
| 5/8 | 15 | 3 | 3 | ||
| 5/8 | 18 | 3 | 3 | ||
| 5/8 | 24 | 3 | 3 | ||
| 3/4 | 8 | 3 | 4 | ||
| 3/4 | 10 | 3 | 4 | ||
| 3/4 | 12 | 3 | 4 | ||
| 3/4 | 15 | 3 | 4 | ||
| 3/4 | 18 | 3 | 4 | Grades | |
| 3/4 | 21 | 3 | 4 | 4.8, 6.8, 8.8, 10.9 / ASTM F1554-36, F1554-55 | |
| 3/4 | 24 | 3 | 4 | Finish | |
| 3/4 | 30 | 3 | 4 | Plain / Hot Dip galvanizing | |
| 3/4 | 36 | 3 | 4 | Thread | |
| 7/8 | 16 | 4 | 4 | DIN, UNC | |
| 7/8 | 18 | 4 | 4 | Packaging | |
| 7/8 | 20 | 4 | 4 | In carton boxes secured in fumigated wood pallets
|
|
